TO · AUTO COUPLING ACCESSORY
TO auto-coupling.
Guide-rail sewage installation.
Published data describes the TO auto-coupling for ISO7005-92 flanged sewage pumps, supplied with seat, adapter and upper guide support so a standard flanged elbow can connect directly on the guide rail.
● Published sewage page 88 · 11 TO sizes · no current selector records
SIZES11
OUTLET40-400 mm
N.W.11-440 kg
FLANGEISO7005-92
Series Overview
Key specifications shared across the TO series.
Published supply includes the coupling seat, coupling adapter, upper guide support and a flange for sizes up to 4 inches. Guide pipe, foundation bolts, expansion bolts and chain assembly are self-provided; accessory bag codes TOPJ-01 through TOPJ-10 map bolt and chain packages to coupling sizes and pump power bands on the same published page.
Model Range
Compare hydraulic performance across all available power ratings.
Weights and packing dimensions below come from the published packing table. Full T/K/h dimension columns remain on the published drawing page for detailed layout.
| Model | Outlet | Bolt circle | N.W. kg | G.W. kg | Packing mm | Guide pipe |
|---|---|---|---|---|---|---|
| TO 40-40(PN6) | 40 / G1.5" | 4-Ø14 | 11 | 13 | 340×260×195 | 1" / Ø32×3 |
| TO 50-50(PN6) | 50 / G2" | 4-Ø14 | 17 | 19.5 | 350×320×245 | 1" / Ø32×3 |
| TO 65-65(PN6) | 65 / G2.5" | 4-Ø14 | 23 | 25.5 | 390×270×345 | 1" / Ø32×3 |
| TO 80-80(PN6) | 80 / G3" | 4-Ø18 | 31 | 34.5 | 410×290×395 | 1.5" / Ø48×3 |
| TO 100-100(PN6) | 100 / G4" | 4-Ø18 | 43 | 48 | 470×330×475 | 1.5" / Ø48×3 |
| TO 150-150(PN6) | 150 | 8-Ø18 | 96 | 111 | 697×437×650 | 1.5" / Ø48×3 |
| TO 150-150(PN10) | 150 | 8-Ø22 | 95 | 110 | 697×437×650 | 1.5" / Ø48×3 |
| TO 200-200(PN10) | 200 | 8-Ø22 | 120 | 136 | 767×437×690 | 1.5" / Ø48×3 |
| TO 250-250(PN10) | 250 | 12-Ø22 | 192 | 213 | 897×507×750 | 1.5" / Ø48×3 |
| TO 300-300(PN10) | 300 | 12-Ø22 | 290 | 317 | 917×617×880 | 2" / Ø60×3.5 |
| TO 400-400(PN10) | 400 | 16-Ø26 | 440 | 483 | 1057×657×1110 | 2" / Ø60×3.5 |
Standard equipment for 150-400 mm outlet sizes does not include the flange. Confirm guide-pipe length formula and TOPJ accessory bag selection against the published page before quotation.
FAQ
Selection questions answered from evidence.
What flange standard does TO use?
Published data states the coupling fixes to pumps with flanges conforming to the ISO7005-92 standard, and that sewage pumps with a standard flanged elbow can connect directly.
What is supplied with the coupling?
Published supply list includes coupling seat, coupling adapter, upper guide support, and flange for sizes ≤ 4". Guide pipe, foundation bolts, expansion bolts and chain assembly are not included.
Which sizes omit the flange?
A published footnote states standard equipment for 150, 200, 250, 300 and 400 mm outlet dimensions does not include the flange.
Are current English selector records available?
No current English selector configuration rows are attached to this Contents entry. The eleven TO codes below come from the published dimensions and packing tables.
